The DRH-48N is DCS’s built-in infrared patio heater, mounted to a wall or overhead structure rather than sitting on a stand, and plumbed into a fixed natural gas line the same way a built-in grill would be. Because it runs on natural gas only, there is no tank to swap if it will not light — the gas supply, the igniter and the flame-sensing safety device are checked in that order.
A unit that lights and then shuts itself off within a few seconds almost always points at that flame-sensing part rather than the gas valve, especially if it has recently been cleaned, bumped out of position, or exposed to a stretch of windy weather. Weak heat output with a visible flame is checked at the emitter face and screen before the burner itself is suspected, since soot and corrosion buildup there is common on a unit that stays outside through every season.
Key Features
- 48-inch built-in, wall-mounted infrared patio heater, natural gas only
- 56,000 BTU output, rated to heat a seating area up to about 15 feet away
- 304 grade stainless steel housing for outdoor installation
Most Common Issues on This Model
Igniter clicks but heater will not light
Heater lights briefly, then shuts back off
Emitter face or screen sooted, rusted or partly blocked, weakening heat output
Flame blows out in windy conditions
